Description
John Deere 3035D
Specifications
Manufacturer
John Deere
Model
3035D
Year
2023
Category
Tractors
Subcategory
Compact Tractor
Hitch type
Category 1
Lift capacity, 24-in.,behind link arms
757.4 kg1670 lb
Cruise control
No
Approximate shipping weight (open-station; cab)
1275 kg2811 lb
Wheelbase
157.4 cm62 in.
Fuel tank capacity
36.7 L,9.7 U.S.gal.
Type
High pressure comm,on rail direct injection
Steering
Power steering
Axle capacity
Front880 kg1940lbRear1600 kg3527 lb
Creeper
No
Differential lock
Yes
Standard
540 RPM,at 2400 RPM
Control
Mechanical
Clutch
Transmission
Brake (for mid and rear PTO)
Wet disc
Crankcase with filter
4.5 L,4.8 qt
Rollover protective structure
TypeFoldableASABE S478
Platform,- flat/straddle
Semi-flat
Gear shift location - console/floor
Right-hand side
Front
Farm,- 7-14Turf - 27x8.5-15R4 - 25x8.5-14
Rear
Farm,- 11.2-24Turf - 41x14-20R4 - 15-19.5
Toolbox
Yes
Tilt Steering wheel
No
Engine power (gross)
25.5 kW,,34.7 hp
Power take-off (PTO) power
23 kW,,30.8 hp
Manufacturer
Yanmar
Engine model
3TNV88C-KJPT
Rated engine speed
2400 RPM
Injection pump type
High pressure comm,on rail direct injection
Aspiration
Natural
Emissions compliance
Final Tier 4
Cylinders/displacement
3 / 1.64 L3 /100.2 cu in.
Number of cylinders
Three
Cylinder liners
Cast-in-block
Bore and stroke
88 x 90 mm,3.46 x 3.54 in.
Compression ratio
19.1:1
Lubrication
Pressurized
Cooling system
Water pump
Air cleaner
Dual element
Engine torque at rated speed
87 Nm64.2 lb-ft
Standard Transmission; forward/reverse
8F/8R synchromesh shuttle shift gear Transmission
Transmission gear ranges
4 gears and 2 ranges
Final drive
Spur Gear
Wheelbase
157.4 cm62 in.
Front Axle clearance
35 cm14 in.
Turning radius with
1.63 m5.3 ft
Left-hand reverser
Yes
Turning radius with brakes
1.63 m5.3 ft
