Description
John Deere DB90 36Row30
Specifications
Manufacturer
John Deere
Model
DB90 36Row30
Year
2023
Category
Tractors
Subcategory
Planter
Number of rows
36, 54
Row unit seed hoppers
Capacity Mini hoppers: 2.2 L 0.0625 bu
Frame - Fold configuration
Front fold
Frame - Flexibility
5-section flex-frame; wing up and down 15 degree (angle)
Fold-and-go from tractor cab
Base
Seed Meters
Base Vacuum Finger pickup NA
Number of cylinders
6
Lift System Type
Electrohydraulic series rephasing cylinder with center sec. drop axle
Tires Base
(8) 31-13.5x15
Tires Quantity
12
Central Commodity System
Seed capacity 3,524 L 100 bu Optional
Drive System Base
3-motor hydraulic variable rate drive
Markers Type
Tri-fold
Row Units Type
ExactEmerge™ row units MaxEmerge™ 5 row units or MaxEmerge 5e row units
Row Units Opener
Tru-Vee Double Disk
Seed Monitor System Base
SeedStar™ electronic system
Tank capacity
1,590 L 420 gal.
Transport weight
15,422 kg, 34,000 lb
Recommended tractor horsepower
Requires a minimum 223.7 kW 300 hp tractor equipped with Category 4 drawbar
Recommended tractor hydraulics
Hydraulic oil pump required to operate electric drive planter: 227 L/min 60 gpm Tractor standby pressure: 15,500 kpa 155 bar (2300 psi) Hydraulic System Working Pressure: 20,684 kPa 207 bar (3000 psi) Hydraulic system burst pressure: 82,737 kPa 827 bar (12,000 psi)
Row unit down force
Pneumatic Base, Infinitely adjustable to 181.4 kg, 400 lb Base equipment
Seed tube sensors
Base equipment
Seed transmission
Frame-mounted
Transmission combinations
Electrohydraulic, on-demand adjustment
Field documentation
Map-based seeding Field documentation Parallel tracking
Warranty length
1 year
