Description
John Deere FM4012
Specifications
Manufacturer
John Deere
Model
FM4012
Year
2023
Category
Mowers
Subcategory
Grooming Mowers
Cutting height- Range, in (cm)
3.8-11.4 cm 1.5-4.5 in
Deck - Thickness, gauge
10 gauge 3.416 mm 0.1345 in
Overlap
15.2 cm 6 in
Lift cylinders
7.6x25.4 cm 3x10 in
Range, in (cm)
2.5-11.4 cm 1-4.5 in
Blade Overlap
3.8 cm 1.5 in
Dimensions, type 1
0.6x6.4 cm 0.25x2.5 in
Size
25.4x10.2 cm 10x4 in
Mainframe
10.2 cm 4 in
Total
3.8 m12.5 ft
Center deck
1.4 m 4.5 ft
Wing deck
1.4 m 4.5 ft
Transport width
2.4 m 7.75 ft
Overall width
3.8 m 12.583 ft
Transport length
3.2 m 10.5 ft
Max overall length
3.4 m 11.25 ft
Transport height
1.8 m 5.9 ft
Cutting width - Total
3.65 m 12 ft
Caster wheels - Type
Solid
Hitch - Drawbar
Category 1
Operating
923.1 kg 2,035 lb
Shipping
950.3 kg 2,095 lb
Operating tongue
145.1 kg 320 lb
Transport tongue
231.3 kg 510 lb
Power
18.6-44.7 kW 25-60 hp
PTO speed rpm
540 rpm
Ratio
1-to-2.5
Splitter gearbox
74.6 kW 100 hp
Mower deck gearbox
26.1 kW 35 hp
Drive Type
Gearbox over V-belt
Wing driveline
Category 3
Input driveline
Category 3 CV
Clevis
Floating
Hitch Adjustment
Self-leveling, multi-position
Wing travel, degrees
Up 20 degree (angle) and down 15 degree (angle)
Discharge type
Rear
Average tip speed
4,938 m/min 16,200 fpm
Spindle quantity
Nine
Spindle type
Cast iron
Spindle bearings
Greaseable ball
Composition
Heat-treated alloy steel
Transport
(2) 20X8-10
Quantity
10
Bearings
Powder metal bushing
Pounds per square inch (kg per square centimeter)
5 pounds per square inch
Belts Adjustment
Spring-loaded idler
Markings
Slow-moving vehicle
