Description
John Deere 648R
Specifications
Manufacturer
John Deere
Model
648R
Year
2023
Category
Mowers
Subcategory
Commercial Mowers
Mower decks Size
48 in 122 cm
Deck thickness
7 gauge 0.180 in 4.6 mm
Height-of-cut range
Increments 0.25 in 0.64 cm 1.5-5 in 3.8-12.7 cm
Cutting width
48 in 122 cm
Length
66 in 167.6 cm
Width
Deflector down, 62 in 157.4 cm
Height
47 in 119 cm
Manufacturer/Model
FX691V
Power
Gross at 3,600 rpm: 22 hp 16.4 kW
Displacement
44.3 cu in 726 cc
Cylinders
Two, V-twin
Crankcase capacity
With filter, 2.2 U.S. qt 2.1 L
Oil filter
Full flow, replaceable
Lubrication
Full pressure
Cooling
Forced air
Air cleaner
Heavy-duty canister type with safety element
Fuel type
Gasoline
Fuel tank capacity
5.6 U.S. gal 21.2 L
Charge system
At 3,600 rpm, 20 amp
Battery voltage
12 V
Transmission
Hydrostatic
Hydraulic pumps
Hydro-Gear with fans, 0.73 cu in 12 cc
Wheel motors
Hydro-Gear, 15 cu in 246 cc
Travel speed Forward
0-9.6 mph 0-15.4 km/h
Travel speed Reverse
0-5.5 mph 0-8.9 km/h
Speed and direction control
Twin hand-controlled levers
Hydraulic capacity
With filter-wet, 2.9 qt 2.7 L Dry, 5 qt 4.7 L
Filter
Spin-on replaceable
Drive wheels
20x10-8 Turf Master
Load rating
4 PR
Dynamic braking
Dual hand-controlled levers
Park brake
Tire engagement
Park brake actuation
Hand lever
PTO Type
Electro-Magnetic with brake, 200 lb-ft 271 Nm
Drive
Dual B-section V-belt with Kevlar® cord
Deck construction
Fabricated steel, floating mount system
Discharge
Side
Blade tip speed
18,900 fpm 5,761 m/min
Number
Three
Caster wheel type
No-flat semi-pneumatic with sealed bearings
Caster wheels
13x6.5-6
Weight
910 lb 412.8 kg
