Description
John Deere 680R
Specifications
Manufacturer
John Deere
Model
680R
Year
2024
Category
Loaders
Subcategory
Front End Loaders For Tractors
Wheelbase
2800 mm 110 in
Dimensions Maximum lift height (A)
4480 mm 176 in
Dimensions At full height - bucket level(B)
4240 mm 167 in
Dimensions At full height - bucket dumped (C)
3465 mm 136 in
Digging depth (H)
96 mm 5 in
Reach At maximum height (D)
1346 mm 53 in
Reach At ground level - bucket level (F)
2931 mm 115 in
Overall length (I+F), ft (m)
5.5 m 17.9 ft
Tractor Model
6175R/M, 6195R/M, 6215R
Front tire
600/70R28
Rear tire
650/85R38
Front axle configuration
MFWD
Pump capacity
114 L/min 30.1 gpm
Rated pressure
200 bar 2900 psi
Base weight
1808.2 kg
Leveling configuration
Mechanical Self Leveling (MSL)
Bucket used
Heavy-duty grapple 2450 mm Heavy-duty grapple 96 in
Bucket weight
375 kg 826 lb
Lift capacity at full height Measured at pivot (U)
2453 kg 5408 lb
Lift capacity at full height Measured at 800 mm ahead of pivot (V)
2431 kg 5359 lb
Lift capacity at 59 in (1500 mm) Measured at pivot (W)
2989 kg 6590 lb
Lift capacity at 59 in (1500 mm) Measured at 800 mm ahead of pivot (X)
2821 kg 6219 lb
Boom breakout force Measured at pivot (Y)
3411 kgf 7520 lbf
Boom breakout force Measured at 800 mm ahead of pivot (Z)
3001 kgf 6616 lbf
Bucket rollback force capacity At maximum height (VV)
3117 kgf 6872 lbf
Bucket rollback force capacity At 59-in (1500-mm) lift height (XX)
4486 kgf 9890 lbf
Bucket rollback force capacity At ground-level line (ZZ)
4336 kgf 9559 lbf
Bucket angle Dump angle, degrees (E)
60 degree (angle)
Bucket angle Rollback angle, degrees (G)
48 degree (angle)
Bucket angle Dump angle, ground
117 degree (angle)
Cycle times Loader raise, seconds
4.19 seconds
Cycle times Loader lower, seconds
2.89 seconds
Cycle times Bucket dump, seconds
1.81 seconds
Cycle times Bucket rollback, seconds
1.81 seconds
