Description
The Bobcat® UT6566 helps you stay comfortable and confident while tackling projects. Its high performance and next-level implement versatility get the job done with efficiency and ease of use.
Specifications
Manufacturer
Bobcat
Model
UT6566
Year
2024
Category
Tractors
Subcategory
Utility Tractor
Horsepower
66.4 hp
PTO HP
51.1 hp
Displacement
149 in³
Engine Model
4HT-TP4A
Implement Hydraulic Flow
10.99 gal/min
Total Hydraulic Flow
19.23 gal/min
Steering Hydraulic Flow
8.24 gal/min
Width
77.2 in
Turning Radius
12' 3"
Wheelbase
6' 10"
Length
148.8 in
Height
99.3 in
Ground Clearance
12.3 in
Front Tire Size
Front Industrial (AG, multi-use) 12.5/80-18 (9.5-24, 340/80R18)
Rear Tire Size
Rear Industrial (AG, multi-use) 18.4-24 (16.9-30, 480/80R26)
Loader Lift Height
10' 9"
Bucket Width
6' 9"
Lift Capacity at 24" behind Lift Point
3,898 lb
Transmission Type
3 Range Powershuttle (w/electronic clutch)
Emissions Tier (EPA)
Tier 4
Number of Cylinders
4
Operating Weight
5,830 lb
Travel Speed
19.8 mph
Travel Speed - Reverse
19.5 mph
3-pt Lift Control Type
Position with Draft Control
3-Point Hitch
Category 2
Rear PTO System
Independent
Rear PTO - RPM
540
Fuel Tank
25.1 gal
Brake Type
Wet Multi Disc
Lift Capacity at Bucket Pivot
3,017 lb
