Description
John Deere XUV 845E
Specifications
Manufacturer
John Deere
Model
XUV845E
Year
2024
Category
Utility Vehicles
Subcategory
Utility Vehicles
Drivetrain Transmission
Continuously Variable Transmission (CVT) with clutch enclosure
Drivetrain Final drive
Park, high, low, neutral, reverse transaxle
Drivetrain Four wheel drive
Dash switch actuated four-wheel drive system
Drivetrain Traction assist
Limited slip front differential, Positive locking, switch actuated rear differential lock
Tires / Wheels Front
25x9-12 Terra Hawk all-terrain on steel wheels 27x9-R14 Maxxis® Bighorn® 2.0 extreme terrain radials on steel wheels 27x11-R14 Predator Heavy-Duty all-terrain radials on steel wheels
Tires / Wheels Rear
25x11-12 Terra Hawk all-terrain on steel wheels 27x11-R14 Maxxis Bighorn 2.0 extreme terrain radials on steel wheels 27x11-R14 Predator Heavy-Duty all-terrain radials on steel wheels
Capacities Weight
With fuel and fluids: 883 kg 1946 lb
Fuel capacity
42.4 L11.2 U S gal
Cargo box capacity (weight)
454 kg 1000 lb
Payload capacity
660 kg 1454 lb
Towing capacity
Up to 1814 kg 4000 lb
Seating
Black vinyl 40/60 split three-passenger bench
Engine Type
4-cycle gas, electronic fuel injection (EFI)
Engine Displacement
812 cc
Engine Power
39.5 kW53 hp
Engine Cooling system
Liquid
Battery / Alternator / Power port
Battery: 12 V 480 CCAAlternator: 85 ampDC outlet: 12 V
Brakes Type
Front/rear hydraulic disc with twin piston front calipers
Suspension Front
Fully independent dual A-arm with adjustable coils; 203 mm (8 in ) of travel
Suspension Rear
Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in ) of travel
Brakes Park brake
Park in-transmission
Capacities Wheelbase
2211 mm 87 in
Capacities Length
3250 mm 128 in
Capacities Width
1625 mm 64.0 in
Capacities Height
1980 mm 78.0 in With roof: 2030 mm 79.9 in
Capacities Tread centers
Front: 1376 mm 54.2 in Rear: 1300 mm 51.2 in
Ground clearance Unloaded:
279 mm 11 in
Cargo box dimensions
1099 x 343 x 1392 mm (43.3 x 13.5 x 54.8 in )
Cargo box volume
524 L18.5 cu ft
