Description
John Deere FM1017
Specifications
Manufacturer
John Deere
Model
FM1017
Year
2024
Category
Mowers
Subcategory
Grooming Mowers
Cutting width
17 ft (5.18 m)
Cutting height range
1-5 in (2.5-12.7 cm )
Wing deck cutting width
6 ft (1.8 m)
Center deck cutting width
6 ft (1.8 m)
Deck overlap
6 in (15.2 cm )
Overall width
206 in (5.23 m)
Transport width
114 in (2.9 m)
Maximum overall length
183 in (4.7 m)
Transport length
161 in (4.1 m)
Transport height
105 in (2.67 m)
Blade dimensions
(9) .25 x 2.5 in (.6 x 6.3 cm )
Blade overlap
1.5 in (3.8 cm )
Transport tires
(2) 20.5 x 8 x 10 in (52.1 x 20.3 x 25.4 cm )
Tractor PTO speed
540 rpm
Drive type
Gear box over v-belt
Tractor horsepower
40-80 hp (30-60 kW)
Splitter gearbox horsepower
100 hp (75 kW)
Mower gearbox horsepower
75 hp (56 kW)
Type
Flex-wing, rear discharge
Hitch
Drawbar
Operating weight
3,450 lb (1,565 kg )
Transport tongue weight
800 lb (363 kg )
Opeating tongue weight
400 lb (181 kg )
Ground pressure
16 ob Psi (110.3 kpa)
Gearbox ratio
1:1.92
Wing driveline
Category 3
Blade composition
Heat-treated alloy steel
Blade spindles
(9) Cast iron
Blade spindle bearings
Tapered Roller
Blade tip speed
18,000 fpm
Cutting height adjustment
Spacer on caster
Hitch adjustment
Self-leveling, multi-position
Input driveline
Category 4 CV
Deck thickness
8-gauge steel plate
Deck lift cylinders
3.5 x 10 in (9 x 25.4 cm ) single acting
Mainframe construction
3 in (7.62 cm ) square tubing
Belts
B section, Kevlar®
Belt adjustment
Spring-loaded idler
Caster wheels
(10) 18 x 9.5 x 8 in (45.7 x 24.1 x 20.3 cm ) pneumatic
Caster wheel bearings
Roller bearings
