Description
John Deere H310
Specifications
Manufacturer
John Deere
Model
H310
Year
2025
Category
Loaders
Subcategory
Front End Loaders For Tractors
Wheelbase
2580 mm 101.6 in
Bucket used
Materials 73 in Materials 1850 mm
Dimensions Maximum lift height (A)
3855 mm 151.8 in
Dimensions At full height - bucket level(B)
3661 mm 144.1 in
Dimensions At full height - bucket dumped (C)
2826 mm 111.3 in
Reach At maximum height (D)
800 mm 31.5 in
Reach At ground level - bucket level (F)
2422 mm 95.4 in
Overall length (I+F), ft (m)
5 m 16.4 ft
Digging depth (H)
31 mm 1.2 in
Tractor Model
6105R/6115R/6125R
Front tire
16.9R24
Rear tire
18.4R38
Front axle configuration
MFWD w/ Limited Slip Differential
Pump capacity
114 L/min 30.1 gpm
Rated pressure
2901 psi 200 bar
Base weight
1356.8 kg
Leveling configuration
Mechanical Self Leveling (MSL)
Bucket weight
620 lb 281 kg
Lift capacity at full height Measured at pivot (U)
3746 lb 1699 kg
Lift capacity at full height Measured at 800 mm ahead of pivot (V)
1846 kg 4070 lb
Lift capacity at 59 in (1500 mm) Measured at pivot (W)
2187 kg 4822 lb
Lift capacity at 59 in (1500 mm) Measured at 800 mm ahead of pivot (X)
2090 kg 4608 lb
Boom breakout force Measured at pivot (Y)
2677 kgf 5902 lbf
Boom breakout force Measured at 800 mm ahead of pivot (Z)
2335 kgf 5148 lbf
Bucket rollback force capacity At maximum height (VV)
1513 kgf 3336 lbf
Bucket rollback force capacity At 59-in (1500-mm) lift height (XX)
3003 kgf 6620 lbf
Bucket rollback force capacity At ground-level line (ZZ)
3059 kgf 6744 lbf
Bucket angle Dump angle, degrees (E)
-7 degree (angle)
Bucket angle Rollback angle, degrees (G)
42 degree (angle)
Bucket angle Dump angle, ground
-95 degree (angle)
Cycle times Loader raise, seconds
2.3 seconds
Cycle times Loader lower, seconds
1.9 seconds
Cycle times Bucket dump, seconds
1.4 seconds
Cycle times Bucket rollback, seconds
1.4 seconds
