Description
John Deere Z320R
Specifications
Manufacturer
John Deere
Model
Z320R
Year
2025
Category
Mowers
Subcategory
Zero Turn Mowers
Frame
Heavy-duty 2.5-in x 2-in (6-cm x 5-cm) front, and 1.5-in x 2-in (4-cm x 5-cm) side tubing
Fore-aft adjustment
2.9 in 7 cm
Mower cut height
1.25-4.5 in 3-11 cm
Cut height increments
0.25 in 0.64 cm
Width of cut
Accel Deep™ mower deck, 42 in 107 cm
Mower deck material
12 gauge 0.105 in 2.7 mm
Wheelbase
49.4 in 1255 mm
Overall length
75.4 in 1915 mm
Width without mower
43.3 in 1100 mm
Width with mower
50.4 in 1280 mm
Width with mower (deflector raised for storage)
46.5 in 1180 mm
Height
43.3 in 1100 mm
Seat back height
High back with armrests, 20 in 51 cm
Power
21.5 hp 16.0 kW
Model number
FR651V
Displacement
44.3 cu in 726 cc
Cylinders
V-twin
Lubrication
Full pressure with replaceable filter, capacity, 2.2 US qt 2.1 L
Type
Overhead valve
Battery
12 V300 CCA
Choke/speed control
Separate levers
Cooling method
Air
Fuel tank capacity
3.0 US gal 11.4 L
Fuel gauge
Translucent tank
Dual hydros
Hydro-Gear EZT-C with 1-in (2.5-cm) axles
Forward speed
0-7 mph 0-11.3 km/h
Reverse speed
0-3.5 mph 0-5.6 km/h
Speed and direction control
Twin levers
Control adjustment
3 height, 11 positions
Primer/paint
E-coat/powder
Front caster tires
11x6-5
Front caster bearings
Sealed ball bearings
Drive tires
18x8.5-8
Maximum towing capacity
250 lb 113 kg
Seat suspension
Two springs
Lift system Type
Foot lift
Mower deck Type
Side discharge
Mower drive system
V-belt
PTO Type
Electric, 105 lb-ft 142 Nm
Drive
V-belt
Weight
572 lb 260 kg
Slope operating limit
13 degrees; 10 degrees with Material Collection System
