Description
John Deere 5120ML
Specifications
Manufacturer
John Deere
Model
5120ML
Year
2025
Category
Tractors
Subcategory
Tractors
Engine type
4045HLV81
Engine family
NJDXL06.8309
Rated speed
2200 rpm
Aspiration
Turbocharged
Cylinders liners
Wet sleeved
Emission level
Final Tier 4
After treatment type
OOS: ERG/DOC/SCR,Cab: EGR/DOC/DPF/SC
Displacement
4 cylinders: 4.5 L,276 cu in
Rated power
At 2200 rpm: 92 kW,120 hp
Rated PTO power (hp SAE)
At 2100 rpm: 77.2 kW,105 hp
Power boost
At 1900 rpm: 4 percent
Maximum engine power
92 kW,125 hp
Engine peak torque
At 1600 rpm: 500 Nm,369 lb-ft
PTO torque rise
At 1600 rpm: 30 percent
Engine rpm (at rated PTO speeds)
540 at 2100 rpm,540E at 1645 rpm,1000 at 2100 rpm
Description
OOS: John Deere PowerTech™ 4045 PWL,Cab: John Deere PowerTech™ 4045 PWS
Clutch; wet/dry
Wet
Creeper
Cab: Powr8™ 32F/16R with creeper
Pump rated output
OOS: Standard: 94 L/min,24.7 gpm,Optional: 117 L/min,31 gpm,Cab: 117 L/min,31 gpm
Available flow at a single rear SCV
OOS: Standard: 70 L/min,18.4 gpm,Optional: 100 L/min,26.4 gpm,Cab: 100 L/min,26.4 gpm
Number of rear selective control valves (SCVs)
Three
Remote control valves available
Three
Hitch category (SAE designation)
Category 2; convertible to 1
Sensing type
Top link
Rear axle differential lock
Electrohydraulic
Drawbar category
Category 2
Maximum vertical load
Road/field use (250-mm extended): 1450 kg 3197 lb,Field use (350-mm extended): 1200 kg 2646 lb,Field use (400-mm extended): 1200 kg 2646 lb
PTO actuation
Electrohydraulic
Category
Cab: Category 2
Standard lift capacity
Cab: 1780 kg (3924 lbs)
Front power take-off (PTO)
Cab: 1000 rpm (21 spline) 34.9 mm (1.375 in)
PTO speed
Cab: 1000 at 2200 rpm
Type
Flange
Final drive type
Inboard planetary
Differential controls
Electrohydraulic
Brakes, type and control
Hydraulic wet disc
Type,One
Mechanical Front Wheel Drive (MFWD)
Rear
19.5L - 24 in 10PR R4 Bias
Wheel tread range
Front: 1299-1997 mm,51.1-78.6 in
Turning radius with brakes
3.34 m,11.0 ft
Turning radius without brakes
3.8 m,12.5 ft
Alternator size
OOS: 90 amp,Cab: 120 amp,ISOBUS/GreenStar™ Ready: 200 amp
Rollover protective structure, OOS
Rigid - foldable - telescopic Foldable, two-post Platform - flat/straddle Flat Gearshift location - console/floor Floor
Seat
OOS: Low Profile,Cab: Air Ride
Display
OOS: Automotive style light-emitting LED instrument cluster,Cab: Digital Dash Display with three liquid crystal displays (LCDs)
Inner cab volume
55 cu ft
dB(A) rating
80 dBA
Safety glass rating
Tempered per SAE J673 and ECE R43-01 requirements
Approximate shipping weight, Open;Cab
Open: PowrReverser™ : 3964 kg 8740 lb,Open: PowrQuad™ PLUS/Powr8™: 4209 kg 9280 lb,Cab: 4826 kg 10640 lb
Fuel tank
Standard for PowrReverser™: 112 L,29.6 US gal,Standard for PowrQuad™ PLUS/Powr8™ models: 144 L , 38 US gal
Diesel exhaust fluid (DEF) tank
12 L,3.17 US gal
Telematic
JDLink™ Modem
Country of manufacture
Saltillo, Mexico
Date collected
6-Jan-2024
