Description
John Deere BP15
Specifications
Manufacturer
John Deere
Model
BP15
Year
2026
Category
Harvesters
Subcategory
Draper Platforms
Auger diameter
66 cm 26 in
Transport widths
5.35 m 17.5 ft
Float range
57 mm 2.25 in
Diameter
66 cm 26 in
Auger fingers
Steel with breakaway notch Diameter: 15.9 mm 0.625 in
Width of belts
1.13 m 3.7 ft
Finger reach
152 mm 6 in
Header height control
Electrohydraulic
Number of belts per pickup
Four picking, four transfer
Total picking width
4.55 m 14.9 ft
Operating speed of belts
3-150 m/min 10-475 fpm
Number of rollers
Two picking, two transfer
Type
Plastic
Number of fingers per belt
84 center belts 77 outer belts
Number of auger fingers
19 STS, maximum 22
Auger finger pattern
In-line, retracting
Operating speed
At 520 feederhouse speed: 15t: 180 rpm 18t: 216 rpm
Adjustment
Toolless
Pressure
1 bar 103.4 kPa 15 psi
Crop deflector
Factory installed
Approximate shipping weight (includes shipping skids)
1647 kg 3630 lb
