Description
John Deere-FL10S Series
Specifications
Manufacturer
John Deere
Model
FL10S Series
Year
2026
Category
Mower Implements
Subcategory
Flail Mowers
Capacity, Cutting (in )
0.79 in
Height, Cutting (in )
.78 /1.57 /2.36 in
Height, Overall (in )
38.7 in
Length, Overall (in )
71.2 in
Width, Cutting (in)
45 in
Width, Overall (in )
52.32 in
Blade Tip Speed (ft/min)
8622 ft
Rotor Diameter (in )
5 in
Rotor Thickness (mm)
8 mm
Rotor Work Diameter (in )
12.63 in
Gauge Roller Diameter (in )
5.5 in
Hydraulic Quick Coupler Size (in )
1/2 in
Frame Thickness (mm)
3 mm
Side Frame Thickness (mm)
4 mm
Roller Bearing Diameter (in)
2.4 in
Primary Pulley Diameter (mm)
225 mm
Secondary Pulley Diameter (mm)
140 mm
Hood Height (in )
15.35 in
Side Case Height (in )
25.2 in
PTO Yoke Height (in )
19.29 in
Weight (lbs)
592 lb
Tractor HP Required (min - max)
15 - 45 hp
Tractor Weight MINIMUM (lbs)
2600 lb
COG (in)
45.6 in
Hitch Type
3-point
Hitch Category
1
Hitch Position
Offset
Offset Range
Left of Center (21.5)Fully Extended (68)
Blade Type
Hammers (std); Y-Blade (service)
Number of Hammers
24
Type of Blades/ Hammers
19 / 21
Rotor Speed (rpm)
2600 rpm
Rotor Bearing Type
SPHERICAL ROLLER 22207
Gear Box Speed (rpm)
540 rpm
Drive Belts
2 - SPB Lp=1160
Rear Roller Bearing Type
D30 D62 B20 2206E 2RS1
Belt adjustment
Screw adjustment
