Description
Bobcat B32S-7
Specifications
Manufacturer
Bobcat
Model
B32S-7
Year
2025
Category
Forklifts
Subcategory
Electric Counterbalance Forklifts
Battery Voltage
48 v
Battery Type
Lead-acid
Travel Speed - Unloaded
11.2 mph
Travel Speed - Loaded
11.2 mph
Maximum Gradeability Loaded
28 %
Maximum Drawbar Pull Loaded
3573 lbs
Rated Capacity
6400 lbs
Maximum Drawbar Pull Unloaded
2690 lbs
Maximum Gradeability Unloaded
32 %
Service Weight (with min, weight of battery)
10869 lbs
Axle Loading, Loaded front/rear
7135 / 995 kg
Drive Motor Rating at S2 60 minute
20.8 hp
Lift Motor Rating at S3 15%
23 hp
Lift Speed - Unloaded
118.1 ft/min
Lift Speed - Loaded
98.4 ft/min
Lowering Speed - Unloaded
90.6 ft/min
Lowering Speed - Loaded
90.6 ft/min
Fork Dimensions
45 / 125 / 1050 mm
Fork Spacing
286 / 1044 mm
Load Center
24 in
Ground Clearance Loaded
4.3 in
Overhead Guard Height
87.4 in
Load Distance, center drive axel to fork
16.2 in
Seat Height
43.2 in
Length To Face Of Forks
86.5 in
Fork Carriage Width
44.5 in
Ground Clearance, center of wheelbase
4.9 in
Aisle Width for pallets 1000 x 1200 crossways
143.8 in
Aisle Width for pallets 800 x 1200 Lengthways
135.9 in
Thread Width, rear
18 x 7-8 in
Overall Length
136.1 in
Tow Coupling Height
122.3 in
Thread Width, front
23 x 10-12 in
Height
84.3 in
Turning Radius
80.3 in
Wheelbase
61 in
Front Tire Size
23 x 10-12 in
Rear Tire Size
18 x 7-8 in
