Description
The 5100E Tractor provides a blend of ergonomic design and high visibility for efficient loader work, powered by a 100 horsepower engine in delivering outstanding performance of agricultural tasks.
Specifications
Manufacturer
John Deere
Model
5100E Open Operator Station
Year
2026
Category
Tractors
Subcategory
Utility Tractors
Engine Make
John Deere PowerTech™ 4045 EWL
Rated Engine Power
102 PS
Maximum Engine Power
102 PS
Transmission Type
PowrReverser™ 16F/16R; Optional: PowrReverser™ Hi-Lo 32F/16R, PowrQuad™ PLUS 16F/16R, Powr8™ 32F/16R, Powr8™ 32F/16R with creeper
Rear Hitch Category (SAE Designation)
Category 2; convertible to 1
Pump Rated Output
PowrReverser™: 94 L/min (24.7 gpm); PowrQuad™ PLUS/Powr8™: 97 L/min (19.3 gpm)
Wheel or Track Configuration
Wheel
PTO Category
540/540E (6 spline); Optional: 1000 rpm (21 spline) reversible shaft
Engagement Method
Electrohydraulic
Front Hitch Category
Category 2
Sensing Type
Lower link
Draft Control Sensing
Mechanical or Electrohydraulic
Drawbar Category
Category 2
Maximum Vertical Load
Road/field use (250-mm extended): 1450 kg / 3197 lb; Field use (350-mm extended): 1200 kg / 2646 lb; Field use (400-mm extended): 1200 kg / 2646 lb
Front Axle Type
Mechanical Front Wheel Drive (MFWD)
Rear Axle Type
Flange (Standard), Rack-and-pinion (Bar) (Optional)
Rear Differential Lock
Electrohydraulic
Differential Controls
Electrohydraulic
Final Drive
Inboard planetary
Primary Brakes
Hydraulic wet disc
ROPS Type
Foldable, two-post
Gearshift Location
Floor
Seat Suspension
Mechanical (Standard), Air Ride or Premium Air Ride (Optional)
Guidance
Optional: AutoTrac™ with AutoTrac Basic
ISOBUS Ready
Optional with PowrQuad™ PLUS/Powr8™ models
Fuel Tank Capacity
Open: 37.7; Cab: 43.7 gal
Country of Manufacture
Pune, India
Date Collected
2023_01_06T00:00:00.0000000
Engine Make
John Deere PowerTech™ 4045 EWL
Emissions Certifications
Final Tier 4
Aspiration
Turbocharged/air-to-air aftercooled
Cylinder Liners
Wet sleeved
Aftertreatment Type
DOC/SCR
Rated Engine Power
102 PS
Maximum Engine Power
102 PS
Maximum Engine Torque
396 Nm / 292 lb-ft
Transmission Type
PowrReverser™ 16F/16R; Optional: PowrReverser™ Hi-Lo 32F/16R, PowrQuad™ PLUS 16F/16R, Powr8™ 32F/16R, Powr8™ 32F/16R with creeper
Creeper
Powr8™ 32F/16R with creeper
Reverser
Left hand, electrohydraulic
Clutch
Wet
Rear Tires Size
18.4R30 (460/85R30) R1W Radial
Wheel Tread Range
Front: 1299–1997 mm / 51.1–78.6 in, Rear: 1350–2286 mm / 53.1–90 in
Hydraulic System Type
Open center
Pump Rated Output
PowrReverser™: 94 L/min (24.7 gpm); PowrQuad™ PLUS/Powr8™: 97 L/min (19.3 gpm)
Available Flow at a Single Rear SCV
70 L/min / 18.4 gpm
SCV Control
Mechanical
Alternator Capacity
OOS: 90 amp; Cab: 120 amp, ISOBUS/GreenStar™ Ready: 200 amp
Working Lights
Halogen (Standard), LED (Optional)
Driving Lights
Halogen (Standard), LED (Optional)
Primary Display
PowrReverser™: Automotive-style light-emitting diode (LED) instrument cluster; PowrQuad™ PLUS/Powr8™: Digital Dash Display with three liquid crystal displays (LCDs)
