Description
For premium performance and comfort, the 6R Tractors are for you. Perfect for long days in the hay field, property management or chores on the farm, ranch, or worksite. Optional precision technology lets you add as much in-cab intelligence as you want.
Specifications
Manufacturer
John Deere
Model
6R 260
Year
2026
Category
Tractors
Subcategory
Utility Tractors
Engine hp
286 Max (213 kW) / 260 hp (194 kW) With up to 40 Additional hp (30 kW) (IPM)
Engine Make
John Deere
Engine Model
PowerTech™ PSS
Engine Family
VJDXL06.8309
Emissions Certifications
Final Tier 4
Displacement
6.8 L
Aspiration
Turbocharged, variable geometry turbo with fixed geometry turbo in series, air-to-air aftercooling and cooled exhaust gas recirculation
Number of Cylinders
6
Cylinder Liners
Wet-sleeve
Aftertreatment Type
Cooled exhaust gas recirculation (EGR), Diesel Particle Filter (DPF) with Diesel Oxidation Catalyst (DOC) and Selective Catalytic Reduction (SCR) using DEF
Intelligent Power Management (IPM)
40
Rated Engine Speed
2100 rpm
Rated Engine Power
250 PS
Rated Engine Power with IPM
300 PS
Maximum Engine Speed
1900 rpm
Maximum Engine Power
286 PS
Maximum Engine Power with IPM
305 PS
Maximum Engine Torque
1,217 Nm 897 ft-lb
Constant Power Range
1500 - 2100 rpm
Power Bulge
10 %
Bore and Stroke
4,19 x 5 in
Compression Ratio
16:07:01
Lubrication
Pressure lubrication
Cooling System Type
Liquid
Fuel Type
Ultra-low sulfur diesel
Air Cleaner Type
External dry-filter type air filter with pre-cleaning
Torque Rise
40 %
Engine Make
John Deere
Engine Model
PowerTech™ PSS
Engine Family
VJDXL06.8309
Displacement
6.8 L
Rated Engine Power
250 PS
Maximum Engine Power
286 PS
Transmission Type
Standard: John Deere AutoPowr™/IVT™ 40 km/h Optional: John Deere AutoPowr™/IVT™ 50 km/h John Deere e19™ PowerShift™ 40 km/h & 50 km/h
Rear Hitch Category (SAE Designation)
Category 3/3N
Pump Rated Output
55.5 gpm
Base Machine Weight
21716 lb
Wheel or Track Configuration
Wheel
Drive Type
MFWD
PTO Category
Category 3
Rated PTO Power
213 PS
Rated PTO Power with IPM
250 PS
Economy PTO Speeds
540 rpm / 1,000 rpm
Engine rpm at Rated PTO Speeds (540/540E/1.000)
1950/1721/1950
Engine rpm at Rated PTO Speeds (540E/1000/1.000E)
1618/2012/1659
Engagement Method
Electrohydraulic switch
PTO Clutch
Multi-disk
Number of Splines
6 and 21
PTO Speed
1000
Front PTO Rotation
Clockwise rotation (viewed in direction of travel)
Engine rpm (at Rated PTO Speeds)
1966 rpm
Maximum PTO Power
156 PS
Engine rpm (at Maximum PTO Speeds)
1966 rpm
Front Number of Splines
21
Front Hitch Category
Category 3N
Lift Capacity Through Full Lift Range at Coupling Points
9700 lb
Maximum Lift Capacity at Coupling Points
13007 lb
Number of Front Selective Control Valves (SCVs)
Two
Electric Power
ISOBUS Connector
Maximum Lift Capacity Directly at Coupling Points
21,820 lb
Lift Capacity Through Full Lift Range Directly at Coupling Points
15,430 lb
Lift Capacity Through Full Lift Range at 610-mm Behind Hitch Point
6700 kg / 14770 lb
Sensing Type
Electrohydraulic sensing
Drawbar Category
Cat 3
Maximum Vertical Load
6,612 lb
Front Axle Type
Triple Link Suspension (TLS Pro™) MFWD axle, Hydro-pneumatic, permanently active, triple link, self levelling suspension
Rear Axle Type
Inboard planetary three pinion
Final Drive
Three planetary gear reduction
Steering Type
Dynamic Load Sensing Reactive Command Steering (RCS)
Primary Brakes
Hydraulic actuation of rear axle brake and front axle brake (optional)
Secondary Brake
Electo hydraulic actuated, integrated into service brake
Trailer Brakes
Optional: Air and/or hydraulic
Parking Brake
Intergrated parking brake
Gearshift Location
CommandArm™
Db(A) Rating
71 dBA
Seat Suspension
Mechanic / Pneumatic
Degree of Seat Swivel, Left Hand
16 degree (angle)
Degree of Seat Swivel, Right Hand
32 degree (angle)
Primary Display
Cornerpost Display
Guidance
SF-RTK
Receiver
Intergrated StarFire™ 7500
Connectivity
JDLink™ Modem
Fuel Tank Capacity
107 gal
Diesel Exhaust Fluid (DEF) Tank Capacity
5.5 gal
Cooling System Capacity
9 gal
Transmission - Hydraulic System
21.9 gal
Crankcase Oil Volume
6.2 gal
Country of Manufacture
Germany
Date Collected
8-Jun-26
Maximum Permissible Weight
33069 lb
Transmission Type
Standard: John Deere AutoPowr™/IVT™ 40 km/h Optional: John Deere AutoPowr™/IVT™ 50 km/h John Deere e19™ PowerShift™ 40 km/h & 50 km/h
Maximum Speed Forward
50 km/h 31 mph
Minimum Speed Forward
0.03 km/h 0.02 mph
Reverser
Left-hand electrical reverser
Hydraulic System Type
Closed-center, pressure/flow compensated system
Pump Rated Output
55.5 gpm
Maximum Operating Pressure
2973 psi
Number of Rear Selective Control Valves (SCVs)
Six
SCV Control
Electrohydraulic
Battery Voltage
12 V
Electrical System Voltage
12 V
Battery Cold Cranking Amps
1800 CCA
Battery Capacity
174 Ah
Alternator Capacity
250
Inner Cab Volume
102.4 cu ft
Cab Glass Area
63.5 sq ft
Secondary Display
10,1 / 12.8 inch Command Center Display
Wheelbase
114.0 in
Overall Height
129.3 in
Transport Height
145.4 in
Overall Width
100.4 in
Overall Length
204.3 in
