Description
Do more with less effort using the 1025R Sub-Compact Tractor. With Quick Connect implement compatibility, you can move seamlessly from mowing to loader work to snow removal without wasting time on complicated attachment changes. Ideal for homeowners and small-scale landscapers who value versatility, ease of use, and the confidence of John Deere reliability.
Specifications
Manufacturer
John Deere
Model
1025R
Year
2026
Category
Tractors
Subcategory
Compact Tractors
Rear Hitch Category (SAE Designation)
Limited Category 1
Pump Rated Output
24 L/min 6.3 gpm
Base Machine Weight
1556 lb.
Wheel or Track Configuration
Wheel
Rated PTO Power
18 hp
Economy PTO Speeds
Rear: 540 rpm; Mid: 2100 rpm
Engagement Method
Independent
PTO Clutch
Wet disk
Brake (For Mid and Rear PTO)
Wet disk
Lift Capacity Through Full Lift Range at 610-mm Behind Hitch Point
344 kg 758 lb
Draft Control Sensing
Position control
Drawbar Category
Position control
Final Drive
Spur gear
Steering Type
Power
Primary Brakes
Wet disc
ROPS Type
Foldable
Gearshift Location
Left-hand side
Seat Suspension
Premium seat
Fuel Tank Capacity
6.3 gal.
Transmission - Hydraulic System
3.2 gal.
Crankcase Oil Volume
2.9 gal.
Engine Make
Yanmar®
Engine Model
3TNV80F-NCJT
Emissions Certifications
Final Tier 4
Displacement
1.267 L
Aspiration
Natural
Number of Cylinders
3
Cylinder Liners
Cast-in-block
Rated Engine Speed
3200 rpm
Rated Engine Power
24 PS
Engine Torque at Rated Speed
39.2 lb-ft
Bore and Stroke
3.15 x 3.31 in.
Compression Ratio
23.1:1
Lubrication
Pressurized
Cooling System Type
Water pump
Fuel Type
Diesel
Air Cleaner Type
Dual element with mechanical restriction indicator
Transmission Type
Hydrostatic - two range
Front Tires Size
R3 Turf: 18x8.50-10; R3 Turf Radial: 18x8.50-10; R4: 18x8.5-10
Front Tread Spacing
37 in.
Rear Tread Spacing
35 in.
Hydraulic System Type
Open center
Pump Rated Output
24 L/min 6.3 gpm
Maximum Operating Pressure
2000 psi
Number of Rear Selective Control Valves (SCVs)
3
Electrical System Voltage
12 V
Battery Cold Cranking Amps
500 CCA
Alternator Capacity
40 amp
Wheelbase
57.1 in.
Base Machine Weight
1556 lb.
Front Axle Ground Clearance
7.7 in.
